DIY Rainwater Collection System Plan | Double IBC Tote Enclosure & Storage Shed
Harvest rainwater efficiently and keep your garden thriving all season long. This complete DIY rainwater collection system plan and rainwater harvesting blueprint provides step-by-step guidance to build a heavy-duty wooden IBC tote enclosure that discreetly houses two standard water tanks inside an attractive, functional backyard structure.
Standard plastic IBC totes offer incredible water storage capacity, but exposed plastic can degrade quickly and look messy in your yard. This custom water barrel housing solves both problems: a sloped roof acts as a durable rain tank cover, blocking UV rays to prevent algae growth while sheltering your tanks from harsh weather.
Whether you need a reliable off-grid water tank setup, an aesthetic rain barrel stand, or a downspout-fed garden water station for drip irrigation, this comprehensive IBC tote shed plan delivers the exact framework needed.
📐 Finished Dimensions
Width: 110 in (279 cm)
Depth: 53-1/2 in (136 cm)
Height: 78-5/8 in front / 70-9/16 in back (sloped roof design)
Capacity: Sized to fit two standard 275-gallon (1000L) IBC totes side-by-side
✨ Key Features
Heavy-Duty Framework: Engineered to support plumbing and provide long-lasting stability.
Front Access Design: Built-in clearances for effortless valve, spigot, and garden hose operation.
Versatile Water Setup: Easily connects to residential gutter downspouts or filtration systems, with a roof angle optimized for supplemental runoff collection.
Algae & Weather Protection: Enclosed structure prolongs tote lifespan and keeps water cool and clean.
🧰 What's Included in This Rainwater System PDF
Instant digital PDF download (printable standard letter/A4)
Clear, step-by-step woodworking instructions with detailed 3D diagrams
Complete material shopping list (lumber, corrugated roofing, screws, and hardware)
Precise cut list with dimension callouts to minimize scrap and reduce material costs
⚠️ Please Note
This is an INSTANT DIGITAL DOWNLOAD (PDF). No physical product, lumber, or hardware will be shipped.
Files are available to download immediately after purchase via your Etsy account.
Build a durable, high-capacity garden water station that upgrades your property's curb appeal and self-sufficiency. 💧🔨
